Three way pipe fittings

Three way pipe fittings
Introduction to three-way products

1. Product Overview
A tee is a type of pipeline connector mainly used for diverting or merging fluids, widely used in fields such as petroleum, chemical, water treatment, and construction. According to their structure and purpose, tees can be divided into equal diameter tees and reducing tees.

2. Product classification
Equal diameter tee: Three interfaces with the same diameter are suitable for situations where the requirements for diversion or merging are the same.
Reducing tee: With different interface diameters, it is suitable for situations where flow needs to be changed.

3. Material
Stainless steel: corrosion-resistant, suitable for the chemical and food industries.
Carbon steel: High strength, suitable for high-pressure and high-temperature environments.
PVC/CPVC： Corrosion resistant, suitable for water treatment and chemical industries.
Copper: Good thermal conductivity, suitable for HVAC and refrigeration systems.

4. Connection method
Welding type: connected by welding, with good sealing performance, suitable for high-pressure and high-temperature environments.
Threaded type: Connected by threads, easy to install, suitable for low-pressure environments.
Flange type: Connected by flanges for easy disassembly and maintenance, suitable for large-diameter pipelines.

5. Technical parameters
Size range: DN15-DN2000（1/2″-80″）
Pressure level: Sch5s-Sch160
Execution standards: ASME B16.9, GB/T12459, HG/T21635, etc

6. Application Fields
Oil and natural gas: used for transporting and distributing oil and gas.
Chemical industry: used for transporting corrosive media.
Water treatment: used for water supply and drainage systems.
Architecture: Used for HVAC and plumbing systems.

7. Product advantages
High strength: able to withstand high pressure and high temperature.
Corrosion resistance: suitable for various media.
Easy installation: Multiple connection methods to meet different needs.
Long lifespan: High quality materials and craftsmanship ensure long-term use.

8. Selection suggestions
According to the medium: choose materials that are suitable for the characteristics of the medium.
According to pressure: choose a model that can withstand system pressure.
Select materials suitable for the working temperature based on temperature.
Select the appropriate connection method based on the installation environment.

9. Maintenance and upkeep
Regular inspection: Ensure no leakage or corrosion.
Cleaning: prevent impurities from accumulating.
Replacement: If any damage is found, replace it promptly.

summarize
Three connections are important components in pipeline systems, and proper selection and maintenance can improve system efficiency and safety.
